Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | 560PSU01 |
| ABB Part Number | SAPROD1KGT006600R0002 |
| Module Type | Power Supply Unit for RTU560 |
| Input Voltage | 100–240 V AC |
| Output Voltage | 24 V DC |
| Output Current | 5 A maximum |
| Power Rating | 120 W |
| Efficiency | >90% |
| Operating Temperature | -20°C to 60°C |
| Humidity Range | 5% to 95% RH, non-condensing |
| Mounting | Panel-mounted or DIN-rail |
| Protections | Overvoltage, short-circuit, and overload protection |
| Dimensions (HxWxD) | Approx. 120 mm x 35 mm x 200 mm |
| Weight | Approx. 0.8 kg |
| Reliability / Lifetime | Designed for long-term continuous operation |
FAQ
A1: Yes, it is specifically designed for ABB RTU560 remote terminal units.
Q2: What is the output voltage and current?
A2: The module provides 24 V DC with a maximum output current of 5 A.
Q3: Can it operate under industrial environmental conditions?
A3: Yes, it functions reliably from -20°C to 60°C and under 5–95% non-condensing humidity.
Q4: What protections are included?
A4: The PSU has overvoltage, short-circuit, and overload protection for safe operation.
Q5: How easy is installation and replacement?
A5: The compact modular design allows simple plug-and-play installation on panels or DIN rails.
