Overview
Specification
| Parameter | Specification |
|---|---|
| Model | 3805E |
| Module Type | Analog Output Module |
| Manufacturer | Triconex |
| Number of Channels | 4 or 8 channels, configurable |
| Output Signal Type | 4–20 mA, 0–20 mA, or 0–10 V |
| Maximum Output Load | 500 Ω per channel |
| Accuracy | ±0.1% full scale |
| Resolution | 16-bit digital-to-analog conversion |
| Response Time | <10 ms typical |
| Power Supply | 24 V DC nominal |
| Operating Temperature | 0°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Mounting | DIN rail or chassis mount |
| Status Indicators | LEDs for power and channel status |
| Compliance / Standards | IEC 61508 SIL 3, CE certified |
| Dimensions (L×W×H) | 125 mm × 40 mm × 120 mm |
| Weight | Approx. 0.45 kg |
FAQ
A1: The module supports 4–20 mA, 0–20 mA, and 0–10 V analog outputs.Q2: How many channels are available per module?
A2: The 3805E is configurable with 4 or 8 analog output channels.
Q3: Is the module SIL certified?
A3: Yes, it is SIL 3 certified for safety-critical applications.
Q4: What is the typical response time for outputs?
A4: Output response time is typically under 10 milliseconds.
Q5: Can it integrate with existing Triconex systems?
A5: Yes, it is fully compatible with Triconex 3800 series controllers and I/O racks.
Q6: What temperature range can the module operate in?
A6: The module operates reliably between 0°C and 70°C.
