Overview
This advanced transducer system includes a 3300 NSv probe, an extension cable, and a 3300 XL NSv Proximitor Sensor. Together, they offer precise non-contact measurement for both small shafts and flat targets, ensuring high accuracy in demanding environments. In addition, the probe’s compact structure and excellent signal stability make it a preferred choice for radial vibration, axial position, and Keyphasor reference applications.
Moreover, the 3300 XL NSv system supports straightforward upgrades from older 3300 RAM installations without requiring extensive reconfiguration. Therefore, engineers can enhance monitoring capabilities while maintaining system continuity and reducing downtime. Its robust design and wide approval range further ensure dependable performance in diverse industrial environments.
Specification
| Parameter | Specification |
|---|---|
| Model | 330901-00-12-70-02-05 |
| Product Type | 3300 XL NSv Proximity Transducer Probe |
| Power Supply | -17.5 Vdc to -26 Vdc (12 mA max consumption) |
| Supply Sensitivity | <2 mV change per volt input variation |
| Output Resistance | 50 Ω |
| Probe Type | Non-contacting eddy-current type |
| Sensing Element | AISI 4140 Steel Target |
| Probe DC Resistance | 0.5 m: 4.0 ± 0.5 Ω / 1.0 m: 4.2 ± 0.5 Ω / 5.0 m: 5.3 ± 0.7 Ω / 7.0 m: 5.9 ± 0.9 Ω |
| Extension Cable Capacitance | 69.9 pF/m (21.3 pF/ft) typical |
| Extension Cable Resistance | Center: 0.220 Ω/m; Shield: 0.066 Ω/m |
| Field Wiring | 0.2–1.5 mm² (16–24 AWG), max length 305 m (1000 ft) |
| Linear Range | 1.5 mm (60 mils), from 0.25 to 1.75 mm (10–70 mils) |
| Recommended Gap | 1.0 mm (40 mils) |
| Incremental Scale Factor (ISF) | 7.87 V/mm (200 mV/mil) ±12.5% / -20% |
| DSL (Deviation from Straight Line) | ±0.06 mm (±2.3 mils) |
| Operating Temperature | 0°C to +45°C |
| Altitude Limit | Up to 2000 m |
| Compliance | CE, ATEX, and CSA/NRTL certifications |
| Total Length Option | 7.0 meters (23.0 feet) |
| Connector and Cable-Type Option | Miniature coaxial ClickLoc connector, standard cable |
| Agency Approval Option | Multiple Approvals |
FAQ
This probe works seamlessly with Bently Nevada 3300 XL NSv Proximitor Sensors and associated vibration monitoring systems.
Q2: Can the probe be used in high-temperature environments?
It operates reliably from 0°C to +45°C. For higher temperatures, specialized probe options are available.
Q3: Is this probe suitable for small shaft vibration measurement?
Yes, it is specifically designed for compact machinery and small shaft applications with tight installation spaces.
Q4: Does the probe meet global safety standards?
Yes, it carries CE, ATEX, and CSA/NRTL certifications, ensuring full compliance with international safety standards.
