Overview
The ABB TU851 3BSE068782R1 extended module termination unit provides a dependable interface for field wiring within S800 I/O systems. It supports seamless integration into Advant OCS and 800xA platforms while ensuring consistent and organized signal transmission. Moreover, its extended termination design accommodates higher wiring density, which helps optimize cabinet layouts in complex automation environments.
System integrators value the TU851 for its balance between flexibility and reliability in demanding industrial applications. In addition, the structured terminal arrangement simplifies installation tasks, allowing technicians to reduce wiring errors and commissioning time. Therefore, it contributes significantly to efficient project execution and long-term operational stability.
Key Features and Functional Benefits
The TU851 offers extended termination capabilities that support high-density I/O signal connections across various industrial control systems. Moreover, its rugged construction ensures reliable performance under harsh environmental conditions, including vibration and temperature fluctuations.
In addition, the unit improves signal integrity by providing secure screw terminal connections that minimize electrical interference and connection failures. For instance, clearly labeled terminals allow technicians to quickly identify wiring points during maintenance procedures. Therefore, troubleshooting becomes faster and system downtime is reduced.
Furthermore, full compatibility with ABB S800 I/O modules enables straightforward integration into both new installations and retrofit projects. As a result, engineers can standardize components across multiple systems and simplify spare parts management.
Specification
| Parameter | Specification | Detailed Description |
|---|---|---|
| Product Type | Extended Module Termination Unit | Provides structured interface between field wiring and ABB S800 I/O modules |
| Model | TU851 | Extended design supporting higher channel density and flexible wiring configurations |
| Order Number | 3BSE068782R1 | Official ABB identification number for ordering and system integration |
| System Compatibility | ABB Advant OCS, ABB 800xA, S800 I/O | Fully compatible with ABB distributed control system architectures |
| Mounting Method | DIN Rail Mounting | Supports standard 35 mm DIN rail for secure and efficient installation |
| Connection Type | Screw Terminal Connections | Ensures stable and vibration-resistant wiring termination |
| Channel Capacity | Extended, Module Dependent | Supports multiple I/O signals depending on connected S800 modules |
| Terminal Layout | Clearly Structured and Labeled | Improves wiring accuracy and simplifies diagnostics and maintenance |
| Wiring Capability | Multi-signal Field Wiring | Suitable for both analog and digital signal connections |
| Material | Industrial-Grade Thermoplastic | Provides high insulation strength and long-term durability |
| Operating Temperature | -25°C to +70°C | Reliable operation in harsh industrial environments |
| Storage Temperature | -40°C to +85°C | Protects the unit during storage and transportation |
| Humidity Tolerance | Up to 95% Non-condensing | Ensures stable operation in high-humidity environments |
| Electrical Protection | Safe Signal Isolation | Reduces risk of short circuits, interference, and signal cross-talk |
| Mechanical Resistance | High Vibration Resistance | Designed for heavy industrial applications with continuous mechanical stress |
| Dimensions | Extended Compact Form Factor | Optimized for high wiring density and efficient cabinet space usage |
| Installation | Tool-Assisted Wiring | Enables fast and secure installation using standard tools |
| Maintenance Access | Front-Accessible Terminals | Simplifies inspection, troubleshooting, and replacement tasks |
FAQ
Q1: What is the function of the TU851 termination unit?
The TU851 connects field wiring to S800 I/O modules while ensuring organized and reliable signal transmission.
Q2: Is the TU851 compatible with ABB 800xA systems?
Yes, it fully supports ABB 800xA and Advant OCS distributed control systems.
Q3: What advantages does the extended design provide?
It allows higher channel density and more efficient use of control cabinet space.
Q4: Can the TU851 operate in harsh industrial environments?
Yes, it is designed to withstand wide temperature ranges, vibration, and high humidity.
Q5: Is the TU851 easy to maintain?
Yes, its clear labeling and structured layout simplify maintenance and reduce troubleshooting time.
