Overview
This unit connects field communication interfaces with redundant I/O modules, ensuring stable and consistent signal routing.
Moreover, the design supports high system availability in critical industrial automation environments.
Therefore, engineers often select this termination unit for control architectures requiring redundancy and long-term operational stability.
The ABB TU846 3BSE022460R1 integrates naturally within the ABB S800 I/O family and supports standardized cabinet layouts.
In addition, its mechanical keying prevents incorrect module insertion during installation or maintenance activities.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Model | TU846 3BSE022460R1 |
| Category | Module Termination Unit |
| System Compatibility | ABB Advant OCS, ABB System 800xA |
| Supported Architecture | Redundant I/O configurations |
| ModuleBus Interfaces | Two electrical ModuleBus connections |
| Optical Interface | Connector for ModuleBus optical port |
| Station Addressing | Two rotary switches, address range 0–99 |
| Mechanical Keying | 36 possible keying positions |
| Mounting Method | DIN rail with mechanical latch |
| Orientation | Vertical or horizontal mounting |
| Power Requirement | Passive unit, no internal energy storage |
| Operating Environment | Industrial control cabinets |
| Construction | Industrial-grade plastic housing |
| Maintenance Requirement | No calibration required |
FAQ
Q1: What is the primary function of the ABB TU846 3BSE022460R1?
It provides termination and routing for redundant ModuleBus communication in Advant OCS and 800xA systems.
Q2: Does the TU846 3BSE022460R1 support redundant configurations?
Yes, the unit is specifically designed to support redundant I/O and communication interfaces.
Q3: Does this termination unit require external power?
No, the ABB TU846 3BSE022460R1 is a passive unit with no internal energy storage requirements.
Q4: Is the unit suitable for standard industrial control cabinets?
Therefore, ABB designed the unit for DIN rail mounting in standard industrial enclosures.
Q5: What delivery and after-sales support is available?
We supply new original products, maintain ready stock, ship within 3 days to 2 weeks, and support 30-day quality returns.
