Configured for discrete signal execution in Modicon Premium automation systems, the Schneider Electric TSXDST2472 (TSXDST2472 Output Module) provides direct physical/electrical execution for 24 VDC digital output channels.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | TSXDST2472 |
| Brand | Schneider Electric / Telemecanique |
| Product Line | Modicon Premium Automation Platform |
| Product Type | Discrete Digital Output Module |
| Origin | Not specified |
| Weight | 0.57 kg (1.25 lb) |
| Dimensions | 20.3 cm x 20.3 cm x 5.1 cm |
| Operating Temp | 0 to 60 deg C |
| Power Consumption | Not specified |
| Output Type | Discrete (Digital) Output |
| Output Points | 24 channels |
| Output Voltage | 24 VDC |
| Output Current per Point | 0.5 A |
| Total Output Current | 8 A max |
| Isolation | Channel to logic isolation |
| Response Time | Less than 1 ms |
| Protection | Short-circuit and overload protection |
| Mounting Type | DIN Rail / Rack Mount |
PLC Backplane Communication and I/O Density Scaling
The TSXDST2472 operates as a Modicon Premium digital output component, providing high-density discrete channel expansion for PLC control architectures. The module receives control commands through the automation platform backplane interface and converts internal logic states into external 24 VDC switching signals.
The 24-channel configuration supports I/O density scaling within rack-based PLC installations. Channel-to-logic isolation separates field-side output circuits from internal controller electronics, reducing electrical interference transfer between external loads and the processor system.
Frequently Asked Questions
Q: What type of field signals can the TSXDST2472 control?
A: The TSXDST2472 provides 24 discrete digital outputs designed for 24 VDC field switching applications. Each output channel supports up to 0.5 A current according to the provided specifications.
Q: Does the module provide electrical isolation?
A: Yes. The module includes channel-to-logic isolation between the output circuitry and the internal PLC logic interface.
Q: What protection functions are integrated into the output channels?
A: The module includes short-circuit and overload protection functions for output channel protection during field operation.
Field Installation Guidelines
Install the TSXDST2472 in accordance with the Modicon Premium rack configuration requirements. Verify that the module is correctly seated in the rack connector before applying system power.
Field wiring should be routed separately from high-voltage power cables and sources of electromagnetic interference. Use appropriate cable shielding and connect shields according to the plant grounding practice.
Confirm output load ratings before connecting field devices. The combined output current should remain within the specified module limits. Inspect terminal connections for correct polarity before commissioning.
Maintain proper ventilation around the PLC rack assembly and ensure the installation environment remains within the specified operating temperature range.
