Specification
| Category | Specification |
|---|---|
| Range of Product | Modicon X80 |
| Product Type | Power supply module |
| Backplane Compatibility | Not compatible with BMEXBP..02 |
| Primary Voltage | 100–240 V AC |
| Supply Circuit Type | AC |
| Secondary Power | 10.8 W 24 V DC sensor power16.8 W 24 V DC I/O module & processor power8.3 W 3.3 V DC I/O module logic power |
| Primary Voltage Limit | 85–264 V |
| Network Frequency | 50/60 Hz |
| Network Frequency Limits | 47–63 Hz |
| Apparent Power | 0.07 kVA |
| Input Current | 0.31 A at 240 V, 0.61 A at 115 V |
| Inrush Current | 30 A at 120 V, 60 A at 240 V |
| I²t on Activation | 12 A²·s at 240 V |
| It on Activation | 0.06 A·s at 240 V, 0.03 A·s at 120 V |
| Immunity to Microbreaks | 1 ms |
| Dielectric Strength | 1500 V primary/secondary (I/O logic & power)2300 V primary/secondary (sensor power)1500 V primary/ground500 V 24 V sensor output/ground |
| Vibration Resistance | 3 gn |
| Shock Resistance | 30 gn |
| IP Degree of Protection | IP20 |
| Directives | 2014/35/EU (LVD), 2014/30/EU (EMC), 2012/19/EU (WEEE) |
| Product Certifications | Merchant Navy, CSA, UL, CE, RCM, EAC |
| Standards | EN 61131-2, EN 61000-6-4, EN 61000-6-2, EN 61010-2-201 |
| Ambient Air Temperature (Storage) | -40…85 °C |
| Ambient Air Temperature (Operation) | 0…60 °C |
| Relative Humidity | 5–95 % at 55 °C without condensation |
| Protective Treatment | TC |
| Operating Altitude | 0–2000 m (2000–5000 m with derating factor) |
