Overview
Specification
| Category | Specification |
|---|---|
| Range of Product | Modicon X80 |
| Product Type | Analog Non-Isolated High-Level I/O Module |
| Analog Inputs | 4 |
| Analog Outputs | 2 |
| Input Signal Types | 0–20 mA, 4–20 mA, ±10 V |
| Output Signal Types | 0–20 mA, 4–20 mA, ±10 V |
| Input Impedance | 24 kΩ for current inputs, >100 kΩ for voltage inputs |
| Output Load | 500 Ω max for current outputs |
| Voltage Supply | 19–30 V DC |
| Power Consumption | ≤ 3.5 W |
| Typical Filtering Time | 4 ms |
| Maximum Filtering Time | 7 ms |
| Isolation | Non-isolated |
| Status LEDs | 1 green LED for module RUN, 1 per channel for diagnostics |
| Protection Features | Reverse polarity protection, external fuses recommended |
| MTBF Reliability | 696,000 hours |
| Product Weight | 0.125 kg |
| Installation | DIN rail mountable, compact design for Modicon Quantum racks |
FAQ
Q1: Is the BMXAMM0600 brand new and factory-sealed?
A1: Yes, this module is 100% genuine, factory-sealed, and brand new.
Q2: What is the typical delivery time?
A2: We ship within 3 days to 2 weeks depending on order size, using carriers such as DHL.
Q3: Can it handle both current and voltage analog signals?
A3: Yes, it supports 0–20 mA, 4–20 mA, and ±10 V signals for inputs and outputs.
Q4: Is there a return policy if quality issues arise?
A4: Yes, we offer a 30-day return policy for any quality-related issues.
Q5: How is the module installed?
A5: The module mounts easily on standard DIN rails and integrates with Modicon Quantum X80 racks.
