Overview
Moreover, the BMXDDI3202K ensures strong electrical isolation, low power consumption, and long-term operational durability. Its compact modular design allows smooth installation within dense control cabinets while maintaining efficient space usage. With easy diagnostics and quick response time, it supports seamless machine operation and process optimization.
Specification
| Category | Details |
|---|---|
| Range of Product | Modicon X80 |
| Product Type | Discrete Input Module |
| Number of Inputs | 32 |
| Input Type | Isolated, Current Sink (Logic Positive) |
| Input Voltage | 24 V DC Positive |
| Input Current | 2.5 mA |
| Sensor Compatibility | 2-wire / 3-wire proximity sensors (IEC 60947-5-2) |
| Sensor Power Supply | 19 – 30 V |
| Voltage State 1 (ON) | ≥ 11 V |
| Current State 1 (ON) | ≥ 2 mA |
| Voltage State 0 (OFF) | ≤ 5 V |
| Current State 0 (OFF) | ≤ 1.5 mA |
| Input Impedance | 9.6 kΩ |
| Insulation Resistance | > 10 MΩ @ 500 V DC |
| Power Dissipation | ≤ 3.9 W |
| Filtering Time (Typical) | 4 ms |
| Filtering Time (Maximum) | 7 ms |
| Input Paralleling | Not Supported |
| Typical Current Consumption | 140 mA @ 3.3 V DC |
| MTBF Reliability | 696,320 hours |
| Protection Type | Reverse Polarity Protection |
| External Fuse | 0.5 A Fast Blow (per channel group) |
| Voltage Detection Threshold | < 14 V DC (sensor fault) / > 18 V DC (sensor OK) |
FAQ
Q1: Is the Schneider BMXDDI3202K an original new product?
Yes, it is 100% brand new and factory-sealed.
Q2: Do you have this module in stock?
Yes, we have ready stock available.
Q3: How long does delivery take?
We usually ship within 3 days to 2 weeks, depending on order size.
Q4: Which courier services do you use?
We typically ship via DHL, FedEx, or UPS for fast and secure delivery.
Q5: What is your return policy if there’s a quality issue?
We offer a 30-day return policy for any verified quality issues.
Q6: What are the power and signal characteristics of this module?
It operates at 24V DC positive logic, drawing about 7 mA per input channel, ensuring fast and precise signal acquisition.
