Overview
Specification
| Parameter | Specification / Description |
|---|---|
| Model | IMMFP03R |
| Module Type | Multi-Function Processor Module |
| Processing Capability | High-speed processor supporting multiple analog and digital modules |
| I/O Support | Compatible with Infi 90 & Net 90 digital and analog input/output modules |
| Communication Interface | Serial and parallel interfaces to MFP and logic stations |
| Redundancy | Supports dual-module redundancy configurations |
| Response Time | <5 ms typical for real-time process monitoring |
| Power Requirements | 24 VDC nominal, compliant with Infi 90 system standards |
| Status Indicators | LEDs for processor status, communication, and error diagnostics |
| Operating Temperature Range | –20°C to +60°C |
| Storage Temperature Range | –40°C to +70°C |
| Humidity Range | 5% to 95% non-condensing |
| Vibration Resistance | 2–13.2 Hz, 1.5 mm peak-to-peak displacement |
| Shock Resistance | 15 g, 11 ms half-sine pulse |
| Safety / Compliance Standards | ABB industrial safety, EMC compliance, CE marking |
| Maintenance / Serviceability | Quick replacement and preventive maintenance support |
| Typical Applications | Real-time process control, logic station integration, industrial automation systems |
FAQ
It serves as a high-speed processor coordinating multiple analog and digital modules.
Q2: Can it operate in redundant system configurations?
Yes, it supports dual-module redundancy for critical process control.
Q3: What environmental conditions can it withstand?
It operates reliably between –20°C to +60°C and 5%–95% non-condensing humidity.
Q4: Which modules are compatible with the IMMFP03R?
It integrates with Infi 90 & Net 90 digital and analog I/O modules.
Q5: How is maintenance handled?
The module supports quick replacement and routine preventive maintenance.
Q6: Is it compliant with industrial safety standards?
Yes, it meets ABB industrial safety, EMC, and CE requirements.
