Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | FBM237 / P0914XS |
| Module Type | Isolated Output Module |
| Number of Channels | 8 output channels |
| Output Type | Isolated DC or current outputs (per configuration) |
| Isolation Voltage | 250 V RMS between channels and system common |
| Input Voltage | 24 V DC nominal |
| Communication | I/A Series Fieldbus compatible |
| Module Mounting | Standard Foxboro FBM baseplate installation |
| Operating Temperature | 0 °C to 60 °C (32 °F to 140 °F) |
| Storage Temperature | –40 °C to 85 °C (–40 °F to 185 °F) |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions | Standard FBM module size |
| Weight | Approximately 0.45 kg |
| Compliance | RoHS compliant, industrial safety standards |
FAQ
A1: It provides 8 isolated output channels suitable for DC or current control applications.
Q2: Can it be installed on standard Foxboro FBM baseplates?
A2: Yes, the module is fully compatible with Foxboro FBM baseplates and racks.
Q3: What is the operating temperature range?
A3: The module operates reliably between 0 °C and 60 °C, suitable for standard industrial environments.
Q4: How does isolation benefit my system?
A4: Isolation prevents electrical interference, protects control circuits, and improves overall system reliability.
