Overview
Specification
| Parameter / Attribute | Specification / Details |
|---|---|
| Brand / Manufacturer | ABB |
| Model / Part Number | DSDO115 / REF57160001-NF |
| Module Type | Digital Output Board |
| System Compatibility | ABB Advant OCS Distributed Control Systems |
| Number of Channels | 16 digital output channels |
| Output Type | Relay / Digital output (configurable) |
| Output Voltage | 24 V DC standard (per channel) |
| Output Current | Up to 0.5 A per channel |
| Isolation | Optical isolation between channels and bus interface |
| Mounting / Installation Method | Rack-mounted in ABB Advant OCS racks |
| Diagnostics / Indicators | LED status indicators for each channel |
| Operating Temperature Range | 0°C to 55°C |
| Storage Temperature Range | –20°C to 70°C |
| Power Supply | Supplied through rack backplane |
| Dimensions (WxHxD) | Approx. 100 × 120 × 35 mm |
| Weight | Approx. 0.35 kg |
| Environmental Compliance | Industrial-grade for indoor control cabinet installation |
FAQ
A1: It supports 16 digital output channels, each with LED status indicators.
Q2: Is the module compatible with all ABB Advant OCS systems?
A2: Yes, it is designed to integrate seamlessly with ABB Advant OCS Distributed Control Systems.
Q3: What output voltage and current ratings does it have?
A3: Each channel provides 24 V DC output with up to 0.5 A current capacity.
Q4: Does it include diagnostics for troubleshooting?
A4: Yes, built-in LED indicators and accessible test points allow rapid maintenance and fault detection.
