Overview
Specification
| Parameter | Specification |
|---|---|
| Model | DO815 |
| ABB Part Number | 3BSE013258R1 |
| Manufacturer | ABB |
| Product Type | Digital Output Module – 24V DC |
| Series / System | Advant OCS / 800xA |
| Output Channels | 16 channels |
| Output Type | Current sinking (NPN) |
| Output Voltage | 24 V DC nominal |
| Output Current | 0.5 A per channel maximum |
| Response Time | <5 ms per output |
| Status Indicators | LED per channel |
| Power Supply | 24 V DC from backplane |
| Typical Power Consumption | 3–4 W |
| Dimensions | 186 × 59 × 127 mm |
| Weight | Approx. 0.7 kg |
| Mounting | Advant OCS / 800xA rack mount |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | −40°C to 70°C |
| Humidity | 5%–95%, non-condensing |
| Protection | IP20 (rack-mounted) |
| EMC Compliance | EN 61000-6-2, EN 61000-6-4 |
| Regulatory Compliance | CE, RoHS |
| Energy Storage | None |
FAQ
Q1: Is ABB DO815 an original product?
Yes, DO815 is 100% brand-new and original from ABB.
Q2: Do you have DO815 in stock?
Yes, we maintain DO815 modules in stock for immediate dispatch.
Q3: How quickly can DO815 be shipped?
Shipping usually occurs within 3 days to 2 weeks depending on order quantity.
Q4: Which logistics carriers are commonly used?
We ship via DHL and other trusted international couriers.
Q5: Can DO815 operate reliably under varying electrical loads?
Yes, DO815 is engineered for stable operation with current sinking outputs.
Q6: What is the return policy if quality issues occur?
We support returns within 30 days if any defect arises with the product.
