Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | DO801 |
| ABB Part Number | 3BSE020510R1 |
| Module Type | Digital Output Module |
| Number of Channels | 16 |
| Output Type | Digital, transistor outputs |
| Nominal Output Voltage | 24 V DC |
| Max Output Current per Channel | 0.5 A |
| Total Module Current Capacity | 8 A maximum |
| Switching Frequency | Up to 1 kHz |
| Output Response Time | <1 ms typical |
| Integration / Compatibility | ABB Advant OCS, ABB 800xA, S800L racks |
| Mounting | Rack-mounted |
| Operating Temperature | 0°C to 60°C (standard industrial range) |
| Storage Temperature | -25°C to 70°C |
| Humidity Range | 5% to 95% RH, non-condensing |
| Insulation Voltage | 500 V DC between channels and power rail |
| Isolation | Optical isolation per channel |
| Indicators / LEDs | Channel status indicators |
| Diagnostics | Built-in fault detection for output short-circuits and overloads |
| Safety & Compliance | ABB industrial standard compliance, CE marked |
| Dimensions (HxWxD) | Approx. 120 mm x 25 mm x 200 mm (check datasheet for exact values) |
| Weight | Approx. 0.5 kg |
| Reliability / Lifetime | Designed for continuous operation in demanding industrial environments |
FAQ
A1: Yes, the DO801 integrates seamlessly with ABB Advant OCS and 800xA platforms without additional adapters.
Q2: What is the voltage requirement for the module?
A2: The DO801 operates at 24V DC for all 16 output channels.
Q3: How many output channels are available?
A3: This module provides 16 independent digital output channels for process control applications.
Q4: Can it handle industrial environmental conditions?
A4: Yes, it is built for standard industrial temperature ranges and reliable operation in demanding environments.
Q5: Is technical support available for installation?
A5: ABB provides comprehensive technical support and documentation to ensure smooth integration and configuration.
