Overview
Moreover, this interface ensures fast cyclic communication while maintaining compatibility with standard industrial Ethernet infrastructures.
In addition, ABB designs CI873K01 to simplify controller integration and reduce engineering effort across distributed automation architectures.
Specification
| Category | Specification |
|---|---|
| Model | CI873K01 |
| ABB Part Number | 3BSE056899R1 |
| Manufacturer | ABB |
| Product Category | Ethernet/IP Communication Interface |
| Series / System | ABB Advant OCS / 800xA |
| Supported Controllers | AC 800M Controllers |
| Primary Communication Protocol | Ethernet/IP |
| Communication Role | Ethernet/IP Scanner (Master) |
| Ethernet Standard | IEEE 802.3 |
| Transmission Speed | 10 / 100 Mbps, auto-negotiation |
| Duplex Mode | Full duplex and half duplex supported |
| Ethernet Interfaces | 2 × RJ45 Ethernet ports |
| Network Topologies | Line and star topologies via external switches |
| Redundancy Support | Module redundancy supported at system level |
| Hot Swap Capability | Supported during system operation |
| Backplane Interface | CEX-Bus communication extension |
| Maximum CEX Modules | Up to 12 modules per controller (system-dependent) |
| Power Supply Type | Supplied from AC 800M CEX-Bus |
| Rated Supply Voltage | 24 V DC |
| Typical Current Consumption | Approx. 160 mA at 24 V DC |
| Energy Storage Components | None |
| Electrical Isolation | Galvanic isolation via system architecture |
| Module Height | Approx. 186 mm |
| Module Width | Approx. 59 mm |
| Module Depth | Approx. 127.5 mm |
| Weight | Approx. 0.7 kg including base unit |
| Mounting Method | Installed in Advant OCS / 800xA controller rack |
| Operating Temperature | +5 °C to +55 °C |
| Storage Temperature | −40 °C to +70 °C |
| Relative Humidity | 5% to 95%, non-condensing |
| Protection Rating | IP20 |
| EMC Compliance | EN 61000-6-2, EN 61000-6-4 |
| Regulatory Compliance | CE, RoHS |
| Intended Environment | Industrial control cabinets |
FAQ
Q1: Is the ABB CI873K01 an original new product?
Yes, the CI873K01 is 100% brand-new and original from ABB.
Q2: Do you have CI873K01 in stock?
Yes, we keep CI873K01 modules in stock for immediate order processing.
Q3: How fast can you ship the CI873K01?
We usually ship CI873K01 within 3 days to 2 weeks, depending on order quantity.
Q4: Which logistics services do you use for delivery?
We commonly use DHL and other international express carriers for fast and secure delivery.
Q5: Does CI873K01 support redundant Ethernet connections?
Yes, CI873K01 provides two Ethernet ports that support flexible network configurations.
Q6: What is your return policy if quality issues occur?
If any quality problem appears, we support returns within 30 days after delivery.
