Overview
Moreover, it enables reliable PROFIBUS DP communication between controllers and distributed I/O, therefore supporting continuous process availability.
In addition, the module supports fully redundant architectures, helping plants maintain stable operation during network or module failures.
As a result, engineers frequently deploy the CI820V1 in high-availability environments where communication stability directly influences production performance.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Product Model | CI820V1 |
| ABB Order Number | 3BSE025255R1 |
| Product Type | Redundant Fieldbus Communication Interface (FCI) |
| Supported Protocol | PROFIBUS DP |
| System Compatibility | ABB Advant OCS and ABB System 800xA |
| Redundancy Support | Yes, dual-channel redundant communication |
| Data Transfer Rate | Up to 12 Mbit/s (PROFIBUS DP) |
| Configuration Tool | ABB Control Builder / 800xA Engineering Tools |
| Diagnostics | Module status LEDs and system diagnostics |
| Mounting Method | DIN rail or system rack mounting |
| Power Supply | Provided via system backplane |
| Operating Environment | Industrial control cabinets |
| Application Class | High-availability and mission-critical automation systems |
FAQ
A1: The CI820V1 provides redundant PROFIBUS DP communication between ABB controllers and distributed I/O systems.
Q2: Which ABB control platforms support the CI820V1?
A2: It is designed for seamless integration with ABB Advant OCS and System 800xA platforms.
Q3: Does the CI820V1 support redundant network configurations?
A3: Yes, it supports dual-channel redundancy, therefore improving communication availability and system resilience.
Q4: What industries typically use the CI820V1?
A4: Power generation, oil and gas, chemical processing, and other high-availability industries commonly use this module.
Q5: How do engineers configure the CI820V1 module?
A5: Engineers configure it using ABB Control Builder or System 800xA engineering tools.
Q6: Why is redundancy important for PROFIBUS communication?
A6: Redundancy reduces single points of failure, therefore helping maintain stable control during network or hardware faults.
