Overview
It extends the S100 I/O bus, allowing distributed I/O cabinets without compromising communication stability.
Moreover, ABB engineers this unit for deterministic data transfer in demanding industrial automation environments.
Specification
| Category | Specification |
|---|---|
| Model | CI540 3BSE001077R1 |
| Manufacturer | ABB |
| Product Name | S100 I/O Bus Extension |
| Product Type | I/O Bus Extension Unit |
| Series | ABB Advant OCS |
| Supported I/O System | S100 I/O System |
| Primary Function | Extension and segmentation of S100 I/O bus |
| Communication Type | Parallel S100 I/O bus communication |
| Maximum Bus Extension Length | Up to 500 m total bus length |
| Supported I/O Stations | Multiple remote S100 I/O stations |
| Bus Topology | Linear bus structure |
| Signal Transmission | Deterministic I/O data transfer |
| Electrical Isolation | Galvanic isolation between bus segments |
| Isolation Purpose | Protection against ground loops and electrical noise |
| Supply Voltage | 24 V DC |
| Rated Voltage Range | 24 V DC ±10% |
| Power Supply Source | External power supply |
| Power Consumption | Approx. 6 W |
| Current Consumption | Approx. 250 mA at 24 V DC |
| Energy Storage Components | None |
| Configuration Method | Hardware-based, no software configuration required |
| Diagnostics Indicators | LED indicators for power and bus activity |
| LED Functions | Power status, bus communication status |
| Connection Type | Screw terminal blocks |
| Mounting Method | DIN rail mounting or panel mounting |
| Enclosure Material | Industrial-grade plastic housing |
| Degree of Protection | IP20 |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | −25 °C to +70 °C |
| Relative Humidity | Up to 95%, non-condensing |
| Vibration Resistance | Suitable for industrial control environments |
| EMC Performance | Designed for high electromagnetic interference immunity |
| Typical Installation Location | Control cabinets and remote I/O cabinets |
| Weight | Approx. 1.1 kg |
| Dimensions (H × W × D) | Approx. 230 × 120 × 65 mm |
| Product Condition | Brand-new, original ABB |
