Overview
The ABB TU836V1 3BSE013237R1 extended module termination unit provides a reliable interface between field wiring and S800 I/O modules. It supports structured signal termination within Advant OCS and 800xA systems while maintaining consistent electrical performance. Moreover, the extended design enables higher wiring density, which helps optimize cabinet space in complex automation projects.
Engineers rely on the TU836V1 for stable signal routing and simplified installation across distributed control systems. In addition, the unit offers clearly arranged terminals that reduce wiring errors and accelerate commissioning processes. Therefore, it contributes directly to improved system reliability and reduced engineering time during project execution.
Key Features and Functional Benefits
The TU836V1 supports extended termination functionality, allowing efficient connection of multiple field signals in industrial environments. Moreover, its robust construction ensures reliable operation under demanding conditions, including vibration and temperature variations.
In addition, the unit enhances signal integrity by providing secure and stable electrical connections across all channels. For instance, clearly labeled terminals allow technicians to quickly identify connections during maintenance and troubleshooting. Therefore, downtime decreases while maintenance efficiency improves significantly.
Furthermore, seamless compatibility with ABB S800 I/O modules simplifies integration into both new and existing control architectures. As a result, system designers can standardize hardware components and reduce overall project complexity.
Specification
| Parameter | Specification | Detailed Description |
|---|---|---|
| Product Type | Extended Module Termination Unit | Provides structured field wiring interface for ABB S800 I/O systems |
| Model | TU836V1 | Extended version designed for higher channel capacity and flexible wiring |
| Order Number | 3BSE013237R1 | Unique ABB identifier for ordering and configuration |
| System Compatibility | ABB Advant OCS, ABB 800xA, S800 I/O | Fully compatible with ABB distributed control platforms |
| Mounting Method | DIN Rail Mounting | Supports standard 35 mm DIN rail for quick and secure installation |
| Connection Type | Screw Terminal Connections | Ensures stable, vibration-resistant wiring termination |
| Channel Capacity | Extended, Module Dependent | Supports multiple I/O channels depending on connected S800 modules |
| Terminal Layout | Structured and Clearly Labeled | Improves wiring accuracy and simplifies diagnostics |
| Wiring Support | Multi-signal Field Wiring | Suitable for both analog and digital signal connections |
| Material | Industrial-Grade Thermoplastic | Provides high insulation strength and mechanical durability |
| Operating Temperature | -25°C to +70°C | Suitable for continuous operation in industrial environments |
| Storage Temperature | -40°C to +85°C | Ensures safe storage and transportation |
| Humidity Tolerance | Up to 95% Non-condensing | Reliable operation in high-humidity conditions |
| Electrical Protection | Safe Signal Isolation | Reduces risk of interference, short circuits, and signal cross-talk |
| Mechanical Resistance | High Vibration Resistance | Designed for use in heavy industrial installations |
| Dimensions | Extended Compact Design | Optimized for higher connection density with efficient space usage |
| Installation | Tool-Assisted Wiring | Enables fast and secure installation using standard tools |
| Maintenance Access | Front-Accessible Terminals | Simplifies inspection, replacement, and troubleshooting tasks |
FAQ
Q1: What is the primary function of the TU836V1 module?
The TU836V1 provides structured termination between field wiring and S800 I/O modules for reliable signal transmission.
Q2: Is the TU836V1 compatible with ABB 800xA systems?
Yes, it fully supports ABB 800xA and Advant OCS distributed control systems.
Q3: What advantages does the extended design provide?
It allows higher channel density and more efficient wiring in complex control cabinets.
Q4: Can the TU836V1 operate in harsh environments?
Yes, it supports wide temperature ranges and resists vibration and humidity typical in industrial applications.
Q5: Does the module require frequent maintenance?
No, its durable design and clear labeling minimize maintenance requirements and simplify servicing.
