Overview
Specification
| Specification | Detail |
|---|---|
| Model Number | 1MRK002239-BBr01 |
| Module Type | Industrial DC Power Supply Module |
| Input Voltage (AC) | 100–240 VAC, 50/60 Hz, auto-select |
| Input Current Max | 2.5 A @ 100 VAC (approximate) |
| Input Protection | Fuse and thermal protection built-in |
| Output Voltage (DC) | 24 VDC ±3% |
| Rated Output Current | 5 A continuous |
| Maximum Output Power | 120 W |
| Efficiency | ~85% at full load |
| Ripple & Noise | ≤150 mVp-p at full load |
| Load Regulation | ±5% over full load range |
| Hold-up Time | >20 ms at full load |
| Protection Features | Overload, over-voltage, short-circuit, thermal shutdown |
| Operating Temperature Range | 0 °C to +60 °C |
| Storage Temperature Range | –20 °C to +70 °C |
| Ambient Humidity | 10–95% RH, non-condensing |
| Cooling Method | Natural convection, no fan required |
| Mounting | DIN rail or panel mount (cabinet installation) |
| Enclosure Protection Rating | IP20 (when installed in rack/cabinet) |
| Dimensions (H × W × D) | 125 mm × 35 mm × 120 mm |
| Weight | Approx. 0.6 kg |
| LED / Indicator Status | Power ON indicator for module status |
| Certifications / Compliance | CE, UL, RoHS |
| MTBF (Typical) | >50,000 hours under nominal conditions |
FAQ
A1: It provides stable DC power for ABB PLC and automation systems, ensuring continuous operation.
Q2: Can this module operate in high-temperature industrial environments?
A2: Yes, it is designed for reliable performance between 0–60°C and harsh industrial conditions.
Q3: How is the module installed?
A3: The module is DIN rail mounted, allowing quick and secure installation in control cabinets.
Q4: Does it support redundant power configurations?
A4: Yes, it can be integrated into redundant power systems to enhance overall reliability.
Q5: What is the maximum output current of this module?
A5: The ABB 1MRK002239-BBr01 delivers up to 5 A of stable DC current for connected devices.
Q6: Is this module compatible with ABB PLCs only?
A6: While optimized for ABB PLC systems, it can support other compatible industrial automation equipment requiring 24 V DC power.
