Overview
Specification
| Parameter | Value |
|---|---|
| Product Model | SC510 |
| Part Number | 3BSE003832R91 (Remanufactured) |
| Series / Platform | ABB Advant OCS |
| Function | Submodule Carrier for OCS I/O and Communication Modules |
| Submodule Compatibility | All standard Advant OCS submodules (I/O, comm, specialty) |
| Number of Module Positions | 6–12 positions (depending on configuration) |
| Backplane Type | Passive OCS backplane with bus distribution |
| Backplane Signal Distribution | Addressing bus, power rails, diagnostic bus |
| Backplane Bus Type | Advant OCS / MasterBus compatible |
| Electrical Isolation | Internal bus isolation between module channels |
| Internal Power Distribution | +5 VDC logic rail, +24 VDC module supply (from main rack) |
| Backplane Current Capacity | Up to 2.5 A per logic rail (rack dependent) |
| Module Retention Method | Dual side-rail mechanical locking with rear connector |
| Connector Type | Multi-point OCS backplane plug connector |
| Mounting Method | Standard OCS rack mounting, front-serviceable |
| Chassis Material | Industrial steel frame with anti-corrosion finish |
| Cooling Method | Natural convection airflow through open-frame design |
| EMC Protection | Compliant with IEC 61000 industrial immunity levels |
| Vibration Resistance | 1.0 g, 10–150 Hz (IEC 60068-2-6) |
| Shock Resistance | 15 g, 11 ms (IEC 60068-2-27) |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | –25°C to +70°C |
| Relative Humidity | 5%–95% non-condensing |
| Installation Environment | Control rooms, process cabinets, industrial panels |
| Serviceability | Front removable submodules; no tools required |
| Typical Lifecycle | 15–20 years in normal industrial operation |
| Compliance | CE, ABB internal manufacturing standards |
| Weight | Approx. 1.0–1.3 kg (depending on variant) |
| Dimensions | Standard Advant OCS carrier length × height × depth |
FAQ
A1: It serves as a carrier for Advant OCS submodules, providing mechanical support and backplane connectivity.Q2: Does the SC510 include a CPU?
A2: No, this carrier model does not include a CPU module.Q3: Can the SC510 work with existing Advant OCS racks?
A3: Yes, it fits standard Advant OCS mounting and electrical interfaces.Q4: Is the remanufactured version tested?
A4: Yes, remanufactured units follow ABB’s refurbishment standards to ensure stable performance.
Q5: Which industries commonly use the SC510?
A5: Power generation, metals, chemicals, utilities, and process automation plants.
Q6: What maintenance does the SC510 require?
A6: Routine contact cleaning and periodic rack alignment checks usually ensure long-term reliability.
