Overview
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE) |
| Series | Mark VI IS200 |
| Functional Part Number | IS200ADIIH1AAA |
| Functional Description | Auxiliary Drive to ISBus Interface Board |
| Instruction Manual | GEI-100305 |
| Compatible Drives | AC/DC2000 with LDCC board only |
| Bypass Feature | Maintains ISBus electrical continuity during power down |
| Configuration Method | Local keypad (DS200LDCCH1A/DS200LDCCG1A) or GE Control System Toolbox |
| Diagnostic Features | LED indicators and test points |
| Jumpers / Fuses | None required; board built without fuses or hardware jumpers |
| Application | Gas, steam, and wind turbine drive assemblies |
| Warranty | 3 years (vendor-specific) |
FAQ
A1: No, it is compatible only with AC/DC2000 drives equipped with an LDCC board.Q2: How are configuration settings stored on the board?
A2: Settings are stored on the drive itself and automatically loaded during power-up or system reset.
Q3: What diagnostic features does the board include?
A3: The board offers LED indicators and seven test points to support quick troubleshooting.
Q4: Can the board be configured without special software?
A4: Yes, it can be configured via the local keypad, but software like GE Control System Toolbox simplifies complex setups.
Q5: What is the operating temperature range of the board?
A5: The board operates reliably in temperatures from -30°C to 65°C, suitable for industrial turbine environments.
