Overview
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE) |
| Series | Mark V DS200 |
| Functional Part Number | DS200CDBAG1BDB |
| Functional Product Description | Contactor Driver Board |
| Functional Product Acronym | CDBA |
| Hardware Revisions | 1st Revision: B, 2nd Revision: D, Artwork Revision: B |
| Jumper Configuration | Factory default: pins 1–2; coordinated operation: pins 2–3 |
| Power Supply | 125 VAC, 4 A fuse (user replaceable, 2AG) |
| Connectors | 1TB connector with three cable bundles for signals and power |
| Diagnostic Features | Three test points, potentiometer, LED indicator for operational status |
| Mounting | Rack or assembly integration with Mark V Series systems |
| Applications | Steam, gas, and wind turbine control systems, automated drives |
| Environment | Industrial-grade PCB for reliable operation in harsh conditions |
FAQ
A: It opens and closes contactors to control turbine and drive operations.Q: How does the board support coordinated operation?
A: Adjusting the jumper to pins 2–3 enables coordination with multiple boards.
Q: What diagnostic features are available?
A: LED indicator, potentiometer, and three test points for monitoring performance.
Q: What type of fuse is required for this board?
A: A 4 A, 125 VAC 2AG fuse, which is user-replaceable.
Q: Which turbine types is this board compatible with?
A: Steam, gas, and wind turbine systems within the Mark V Series.
