Overview
Specification
| Specification | Details |
|---|---|
| Manufacturer | General Electric (GE) |
| Part Number | IS200ICBDH1ABA |
| Series | Mark VI Speedtronic |
| Product Type | Control Card |
| Functional Abbreviation | ICBD |
| Revisions | 3 total (2 functional revisions, 1 artwork revision) |
| Assembly Type | Standard assembly with soldered components |
| Connectors | 4 jack connectors (J11A/B, J12A/B) for control signals; 2 female connectors (J9 9-pin D-sub, J10 8-pin mini-DIN) for external I/O; 3 backplane connectors for module integration |
| Input/Output | Multiple digital and analog signals for turbine control and monitoring |
| Key Components | 4 transistors, 3 transformers, 1 fuse, multiple integrated circuits, resistors, and capacitors |
| PCB Protection | Conformal coating for protection against moisture, dust, and temperature variations |
| Operating Temperature | -30°C to 65°C (suitable for industrial turbine environments) |
| Dimensions | Narrow, long card; standard Mark VI backplane form factor; no front faceplate |
| Diagnostic Features | Conduction sensors, reset switch, and status LEDs for troubleshooting and monitoring |
| Compliance | Designed to meet GE Mark VI system standards for reliability and interoperability |
| Mounting | Backplane-mounted within Mark VI chassis; secure locking connectors ensure stable operation |
FAQ
A1: It enables precise monitoring and management of steam and gas turbines within the Mark VI system.
Q2: Can this card be used with older Mark VI systems?
A2: Yes, it is backwards-compatible with previous revisions of the Mark VI backplane.
Q3: What diagnostic features are available on the board?
A3: The board includes conduction sensors, a reset switch, and status LEDs for rapid troubleshooting.
Q4: How is the board protected against environmental conditions?
A4: It features conformal PCB coating that safeguards against moisture, dust, and temperature variations.
Q5: What types of connectors does the card support?
A5: It supports four jack connectors (J11A/B, J12A/B), two female connectors (J9 9-pin D-sub, J10 8-pin mini-DIN), and three backplane connectors.
