Overview
Specification
| Parameter | Value |
|---|---|
| Manufacturer | GE Fanuc / General Electric |
| Model Number | DS200PTCTG1BAA |
| Module Type | Signal Conditioner Card |
| System Platform | GE Mark V Turbine Control |
| Primary Function | Signal filtering, scaling, isolation, routing |
| Signal Types Supported | Analog inputs, current feedback, sensor data |
| Typical Sensor Inputs | Temperature probes, vibration sensors, speed pickups |
| Conditioning Features | Noise filtering, amplitude stabilization, isolation circuits |
| Board Format | DS200 series full-size PCB |
| Hardware Revision | BAA revision level |
| Connector Type | DS200 multi-pin connectors |
| Installation Method | Slot-based rack mounting |
| Operating Voltage | Supplied via Mark V rack |
| Cooling Method | Natural convection cooling |
| Operating Environment | Industrial turbine control cabinets |
| Compatibility | GE Mark V DS200-series frames |
| Maintenance Level | Low maintenance; connector checks recommended |
| Reliability | High-availability industrial-grade performance |
| Typical Applications | Turbine signal processing and feedback conditioning |
FAQ
Yes, it fits standard Mark V frames that accept DS200-series conditioning boards.
Q2: What signals does this module typically handle?
It conditions various analog feedback signals, including current, temperature, and speed-related sensor outputs.
Q3: Does the board require calibration?
It ships pre-aligned, and routine use rarely demands recalibration unless sensors change.
Q4: Can technicians replace it without modifying system wiring?
In most cases, yes. Its connectors follow GE’s standard layout for quick installation.
Q5: What issues indicate the board needs replacement?
Unstable sensor readings, recurring noise, or intermittent control faults may point to a failing conditioning card.
