Overview
Specification
| Parameter | Specification / Description |
|---|---|
| Model | IMFAI02 |
| Module Type | Fast Analog Input Module |
| Number of Input Channels | 8 |
| Sampling Rate | 1 kHz per channel |
| Resolution | 16-bit analog-to-digital conversion |
| Input Signal Type | Voltage or current analog signals (typical 0–10 VDC / 4–20 mA) |
| Communication Interface | Multi-Function Processor Module (MFP) |
| Data Accuracy | High-precision, low-noise measurement |
| Response Time | ≤ 1 ms typical |
| Operating Temperature Range | –20°C to +60°C |
| Storage Temperature Range | –40°C to +70°C |
| Humidity Range | 5% to 95% non-condensing |
| Installation | Module mounts on Module Mounting Unit (MMU) |
| Status Indicators | LEDs for channel activity and module operation |
| Safety / Compliance Standards | ABB industrial safety, EMC compliance, CE marking |
| Maintenance / Serviceability | Quick replacement and routine preventive maintenance |
| Typical Applications | High-speed process monitoring, turbine control, real-time industrial data acquisition |
FAQ
The module supports 8 high-speed analog input channels for simultaneous process monitoring.Q2: What is the sampling rate and resolution of the module?
Each channel samples at 1 kHz with 16-bit resolution, ensuring precise real-time measurements.
Q3: Which signal types can the IMFAI02 measure?
It accepts both voltage and current analog signals, typically 0–10 VDC or 4–20 mA.
Q4: How does the IMFAI02 integrate with Infi 90 systems?
It interfaces directly with Multi-Function Processor Modules (MFP), enabling fast data acquisition and control.
Q5: What environmental conditions can the module operate under?
It is rated for –20°C to +60°C and 5%–95% non-condensing humidity for industrial environments.
Q6: How is the IMFAI02 installed and maintained?
The module mounts securely on a Module Mounting Unit (MMU) and supports quick replacement and routine maintenance.
