Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | DSDO131 |
| ABB Part Number | 57160001-KX |
| Module Type | Digital Output Unit |
| Output Channels | 16 discrete outputs |
| Output Type | Relay / transistor (depending on system setup) |
| Nominal Output Voltage | 24 V DC |
| Maximum Current per Channel | 0.5 A |
| Response Time | ≤ 5 ms |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -20°C to +70°C |
| Relative Humidity | 5–95% non-condensing |
| Mounting | DIN rail / Rack installation |
| Diagnostics | LED indicators per channel |
| Protection Rating | IP20 |
| Country of Origin | Sweden |
FAQ
A: The module offers 16 discrete digital output channels.
Q: Is it compatible with Advant OCS systems?
A: Yes, it integrates seamlessly with ABB Advant OCS automation networks.
Q: What is the maximum current per channel?
A: Each channel can handle up to 0.5 A at 24 V DC.
Q: Can it operate in standard industrial environments?
A: Yes, it functions reliably from 0°C to +60°C with 5–95% non-condensing humidity.
