Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | DSBC173A |
| ABB Part Number | 3BSE005883R1 |
| Module Type | Bus Extender (S100 I/O Bus) |
| Function | Extends communication between I/O modules and main control unit |
| Communication Protocol | S100 I/O Bus |
| Max Bus Length | Up to 50 m (depends on cable type and environment) |
| Number of Bus Segments | 1 main extension per module |
| Data Transfer Rate | Up to 1 Mbps |
| Operating Voltage | 24 V DC ±10% |
| Power Consumption | ≤ 5 W |
| Mounting | DIN rail / Rack mountable |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -20°C to +70°C |
| Relative Humidity | 5–95% non-condensing |
| LED Indicators | Power, Bus OK, Error |
| Protection Rating | IP20 |
| Weight | 0.45 kg |
| Country of Origin | Sweden |
FAQ
A: It extends the S100 I/O bus, allowing additional I/O modules to communicate with the main controller.
Q: Can it be installed without shutting down the system?
A: Yes, the module supports hot-swappable installation for minimal operational impact.
Q: What is the maximum supported bus length?
A: The module supports up to 50 meters, depending on the cable type and environment.
Q: Is it compatible with all ABB Advant OCS modules?
A: It is compatible with S100 I/O modules within the Advant OCS platform.
