Overview
Moreover, the board’s diagnostic-friendly layout incorporates fast-acting fuses and clearly marked test points, enabling maintenance teams to perform rapid troubleshooting and preventive maintenance. In addition, its robust construction combined with high-quality components ensures long-term reliability even in demanding industrial environments. Therefore, it remains a dependable and efficient solution for consistent turbine drive performance, operational safety, and minimized maintenance interruptions.
Specification
| Specification | Details |
|---|---|
| Manufacturer | General Electric (GE) |
| Part Number | DS200FSAAG2ABA |
| Series | Mark V DS200 |
| Functional Acronym | FSAA |
| PCB Coating | Normal coating |
| Functional Revisions | 1st Revision A, 2nd Revision B, Artwork Revision A |
| Key Components | 2 fast-acting fuses (30 A, 60 V), 6 manually-moveable jumpers (JP1–JP6), multiple test points |
| Connectors | 1 10-pin connector, 4 2-pin connectors for field connections |
| Diagnostic Features | Test points and fuses for easy maintenance |
| Mounting | Backplane-mounted within Mark V chassis |
| Typical Environment | Industrial turbine drive assemblies (steam, gas, wind) |
| Operational Notes | Jumpers set for NRP default mode; customizable for other configurations |
FAQ
A1: It amplifies field supply signals and ensures reliable operation of turbine drives.
Q2: Can this board be customized for different operational modes?
A2: Yes, the jumpers can be adjusted to select NRP or alternate modes.
Q3: What diagnostic features are included?
A3: The board has multiple test points and fast-acting fuses for troubleshooting.
Q4: How many connectors are available for field connections?
A4: It includes one 10-pin connector and four 2-pin connectors for cables.
Q5: Is this board suitable for all turbine types?
A5: Yes, it is compatible with steam, gas, and wind turbine drives using Mark V systems.
Q6: How is the board protected against electrical faults?
A6: It uses two 30 A, 60 V fast-acting fuses to prevent damage and ensure safety.
