Configured for backplane extension between distributed rack segments in the Modicon X80 system, the Schneider Electric BMXXBE2005 (BMXXBE2005 backplane extension cable) provides direct physical communication continuity. The cable is supplied with a line terminator and is intended for use with the BMXXBE1000 extension interface while maintaining backplane communication across separated rack assemblies.
Suffix Breakdown & Model Matrix
The supplied documentation identifies BMXXBE2005 as a fixed catalog number. No official suffix decoding or model matrix is specified by the manufacturer.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | BMXXBE2005 |
| Brand | Schneider Electric |
| Origin | Not specified |
| Product Type | Backplane Extension Cable |
| Product Series | Modicon |
| Compatibility | BMXXBE1000 |
| Cable Length | 12 m |
| Kit Contents | Extension cable and line terminator |
| Weight | 1.36 kg |
| Dimensions | Not specified |
| Operating Temp | 0 to 40 deg C |
| Storage Humidity | Maximum 80% RH, non-condensing |
| Operating Humidity | Maximum 80% RH, non-condensing |
| Maximum Operating Altitude | 1000 m without derating |
| Power Consumption | None specified |
| Compliance | Low Voltage Directive, EMC Directive, ATEX |
| Hazardous Area Rating | Class I, Division 2 |
Backplane Bus Communication Compatibility
The BMXXBE2005 is designed to extend the Modicon backplane connection between physically separated rack sections through the BMXXBE1000 interface. The supplied line terminator completes the communication path as required by the backplane architecture. The cable functions as a physical communication medium and does not perform protocol conversion or signal processing.
Frequently Asked Questions
Q: Can the BMXXBE2005 be connected directly between two backplanes without a BMXXBE1000 interface?
A: No. The published compatibility specifies use with the BMXXBE1000 backplane extension interface.
Q: Does the cable include the required termination hardware?
A: Yes. The standard kit consists of the extension cable together with one line terminator.
Q: Does the BMXXBE2005 require a separate power supply?
A: No separate power consumption is specified. The cable serves as a passive backplane extension component.
Field Installation Guidelines
- Verify that both rack sections are compatible with the specified backplane extension architecture before installation.
- Install the supplied line terminator at the designated end of the extension link according to the system hardware manual.
- Route the 12 m cable separately from high-voltage power wiring to minimize electromagnetic interference.
- Maintain the minimum cable bend radius recommended for industrial communication cables and avoid excessive mechanical tension.
- Secure the cable with appropriate supports to prevent connector movement caused by vibration.
- Perform installation only with equipment de-energized unless the system documentation explicitly permits otherwise.
- Confirm that ambient temperature, humidity, and installation altitude remain within the specified operating limits.
