Overview
Specification
| Parameter | Specification / Detail |
|---|---|
| Model Number | IS220PHRAH1B（IS230SNHRH2A) |
| Module Type | HART‑enabled Analog Input / Output Module |
| Compatible Systems | GE Fanuc Mark VIe / Mark VIeS control systems |
| Analog Input Channels | Up to 10 channels |
| Input Signal Types (channels 1–8) | 4–20 mA current loop or 5 V DC voltage input |
| Input Signal Type (channels 9–10) | 4–20 mA current loop or 1 mA current input option |
| Analog Output Channels | 2 channels (4–20 mA current loop) |
| Input Converter Resolution | 16‑bit A/D converter |
| Output Converter Resolution | 14‑bit D/A converter |
| Normal Scan Time | 5 ms scan cycle |
| Output Load Capability | Supports up to 800 Ω load for 4–20 mA outputs |
| Communication Protocol | HART (for analog I/O and smart transmitters) |
| Connectivity / Interface | Dual RJ45 Ethernet ports + standard module backplane / I/O terminal board interface |
| Power Supply / Voltage | 24 VDC nominal typical |
| Operating Temperature Range | –40 °C to +70 °C (depends on revision) |
| Humidity / Environment | 5% to 95% RH, non‑condensing, suitable for industrial conditions |
| Physical Dimensions | Approx. 3.25″ × 1.65″ × 4.78″ (≈ 8.26 cm × 4.19 cm × 12.1 cm) |
| Weight | Around 0.6 kg / ~1.2 lb |
| Isolation / Signal Integrity | Channel-to-channel and channel-to-ground isolation for safe, noise‑resistant operation |
| Compliance / Certification | Meets standard industrial quality and safety requirements typical for Mark VIe series modules |
FAQ
A1: The module supports both voltage (±10 V) and current (0–20 mA, 4–20 mA) signals for versatile analog applications.
Q2: Can this module be used in Mark VIe systems?
A2: Yes, the IS220PHRAH1B integrates seamlessly with both Mark V and Mark VIe GE Fanuc control systems.
Q3: What is the resolution and accuracy of this analog module?
A3: The module offers 16-bit resolution with ±0.1% full-scale accuracy, ensuring precise measurements.
Q4: How does the module handle harsh industrial environments?
A4: Its rugged construction tolerates 0–60°C operating temperature and 5–95% non-condensing humidity.
Q5: Is the module easy to maintain or replace?
A5: Yes, its modular design allows quick replacement and supports efficient system diagnostics.
