Overview
Specification
| Parameter | Description |
|---|---|
| Manufacturer | GE Fanuc / General Electric |
| Model Number | DS200PCCAG1ADB |
| Board Type | Power Connect Card |
| System Platform | GE Mark V Turbine Control System |
| Primary Function | Distribute DC and control power to DS200 modules |
| Input Voltage | Supplied by DS200 system rack power |
| Output Connections | Multiple module connectors for power distribution |
| Protection Features | Overcurrent and short-circuit protection for connected modules |
| Connectors | Edge connectors compatible with Mark V rack |
| Installation | Plug-in rack-mounted card |
| Status Indicators | LED indicators for power presence |
| Operating Environment | Industrial turbine control applications |
| Compatibility | DS200 and Mark V control modules |
| Typical Weight | Approx. 1.0–1.2 kg |
| Maintenance | Routine inspection and connector cleaning recommended |
FAQ
A1: Yes, it is fully compatible with Mark V turbine control systems and other DS200 modules.
Q2: What environment is the card suitable for?
A2: The card operates reliably in industrial conditions with temperature fluctuations and electrical noise.
Q3: Does it require special configuration?
A3: No, it integrates seamlessly into existing DS200 systems without extensive setup.
Q4: How does it improve system reliability?
A4: By distributing power consistently, it reduces downtime risks and enhances module stability.
