Overview
Specification
| Parameter | Specification |
|---|---|
| Product Model | DS200FCRRG1AKD |
| Module Type | Firing Control Circuit Board |
| System Platform | GE Mark V Turbine Control System |
| Primary Function | Generates precise SCR firing pulses for turbine power control |
| Control Features | Timing control, firing signal synchronization, gating accuracy optimization |
| Input Signal Types | Firing references, gate commands, internal logic signals |
| Output Signal Types | SCR gate pulses with high timing precision |
| Signal Processing | Noise filtering, pulse shaping, stability compensation |
| Diagnostics | On-board LEDs, test points, fault detection indicators |
| PCB Structure | Multilayer board with mixed SMT and through-hole components |
| Communication Interface | Internal Mark V backplane signaling |
| Power Source | Supplied through Mark V rack power distribution |
| Operating Temperature | 0°C to +60°C (industrial environment) |
| Thermal Performance | Stable operation under long turbine cycles and heat load |
| Mechanical Format | GE DS200 full-size board |
| Mounting Method | Rack-mounted with card-edge backplane connector |
| Connector Type | GE DS200 standard card-edge connectors |
| System Compatibility | Mark V control modules, power conversion units, SCR turbine circuits |
| Typical Applications | Turbine power firing, rectifier/bridge control, retrofit upgrades |
| Serviceability | Field-replaceable module with modular GE design |
| Compliance | Meets GE industrial reliability and quality standards |
FAQ
A1: It controls precise SCR firing pulses used in Mark V turbine power converters.
Q2: Is the board easy to replace in the field?
A2: Yes, the Mark V modular design allows fast removal and installation with minimal downtime.
Q3: Which systems support this firing board?
A3: It works with GE Mark V turbine control assemblies and DS200 platform modules.
Q4: Does the board include built-in diagnostics?
A4: Yes, on-board indicators and test points simplify troubleshooting and performance checks.
Q5: What industries typically use this model?
A5: Power generation, oil and gas, heavy industrial processing, and turbine-based energy systems.
Q6: Can the DS200FCRRG1AKD improve converter reliability?
A6: Yes, accurate firing control enhances converter stability and reduces operational disturbances.
