Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | DS200FCR2G1AFC |
| Function | Firing Circuit Card for GE Mark V DS200 turbine control systems |
| Compatible Systems | GE Mark V DS200 series control racks and modules |
| Input Voltage | 24 V DC nominal (±10%) |
| Output Type | Solid-state firing outputs with built-in short-circuit protection |
| Number of Channels | 8 independent firing channels |
| Output Current Rating | 0.5 A per channel maximum |
| Response Time | <5 ms typical for firing signal activation |
| Isolation | Galvanic isolation between input and output circuits |
| Operating Temperature | -20 °C to +70 °C |
| Storage Temperature | -40 °C to +85 °C |
| Humidity Tolerance | 5%–95% RH, non-condensing |
| Mounting | Standard DS200 rack installation, front-accessible |
| Indicators | LED status per channel for signal verification |
| Diagnostic Features | Fault detection and channel monitoring |
| Protection Features | Overcurrent, short circuit, and thermal protection |
| Certifications / Compliance | Meets GE Mark V electrical and operational standards |
| Dimensions | 6.4 × 10.2 × 2.5 cm (approximate, rack-compatible) |
| Weight | 0.45 kg (approximate) |
| Environmental Rating | Suitable for industrial turbine environments with electrical noise, vibration, and temperature fluctuations |
FAQ
A1: It is compatible with all GE Mark V DS200 control systems supporting firing circuits.
Q2: How does the card improve turbine system reliability?
A2: By delivering precise firing signals and maintaining operation under harsh conditions, it reduces downtime.
Q3: Can the card be installed without modifying existing DS200 racks?
A3: Yes, it mounts directly into standard DS200 chassis without any additional modifications.
Q4: What maintenance is required for this card?
A4: Routine inspections and status LED monitoring are sufficient to ensure optimal operation.
