Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | 531X307LTBAKG1 |
| Product Type | LAN / I/O Terminal Board (LTB) |
| Compatible Series | GE 531X series drives and exciters |
| Control Input Plugs | 8 configurable inputs (AC or DC) |
| Input Voltage Range | 2–240 V (AC or DC) |
| Logic Output Signal | 24 V DC logic (converted internally) |
| Relay Outputs | 7 × Form‑C relay contacts (low‑voltage, low‑current) |
| Typical Use | Interface for contactors, indicators, interlocks, control devices |
| Function | LAN termination + analog/discrete I/O terminal interface |
| Installation | Mounted inside drive/exciter cabinet; plug‑in / terminal type wiring |
| Compatibility | Drive control board, NTB/3TB terminal board, external I/O devices |
| Environment | Standard industrial control cabinet conditions |
FAQ
A: It accepts AC or DC voltages from 2 to 240 V on its eight configurable control‑input plugs.
A: The board converts inputs into 24 V DC logic signals and provides seven Form‑C relay outputs to drive contactors, lamps, solenoids, or other control devices.
Q: Can this board be used as a drop‑in replacement in existing 531X systems?
A: Yes — it is designed as part of the 531X series and supports direct installation into GE drives or exciters compatible with that series.
Q: What external devices can connect to this board?
A: External devices such as contactors, indicator lights, pushbuttons, interlocks, and other control or monitoring peripherals can connect via the relay outputs or control‑input plugs.
