Overview
Specification
| Parameter | Specification / Details |
|---|---|
| Model Number | DSTV 110 |
| ABB Part Number | 57350001-A |
| Module Type | Master Connection Unit for Video |
| Input Voltage | 24 V DC nominal |
| Video Interfaces | Composite, Y/C, or digital video (module dependent) |
| Number of Video Channels | Up to 4 channels |
| Bandwidth | Up to 60 MHz per channel |
| Signal-to-Noise Ratio (SNR) | ≥ 60 dB |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | –20°C to +70°C |
| Relative Humidity | 5% to 95% RH, non-condensing |
| Mounting / Form Factor | Rack-mounted, ABB cabinet compatible |
| Dimensions (approx.) | 210 mm × 120 mm × 45 mm |
| Weight | Approx. 1.6 kg |
| Compliance / Certification | ABB industrial standards, CE, UL, EMC |
FAQ
A1: It supports composite, Y/C, and digital video interfaces depending on the module configuration.
Q2: How many video channels can it handle simultaneously?
A2: The DSTV 110 can manage up to 4 independent video channels simultaneously.
Q3: Is the unit suitable for harsh industrial environments?
A3: Yes, it operates reliably between 0°C and +55°C with high humidity tolerance.
Q4: Can this unit integrate into standard ABB cabinets?
A4: Yes, it is rack-mounted and compatible with ABB industrial cabinet systems.
Q5: Does DSTV 110 ensure high-quality video signal transmission?
A5: Yes, it minimizes noise and distortion to maintain high-fidelity video performance.
Q6: What is the input voltage for this module?
A6: The nominal input voltage is 24 V DC.
