Overview
Specification
| Parameter | Specification / Details |
|---|---|
| Model Number | DSAV 111 (EXC57350001‑CN) |
| Module Type | Master Video Generator / Video Board |
| Video Output / Format | Composite and/or RGB video signals (depending on display setup) |
| Frame Rate / Refresh Rate | 61.2 Hz standard for video output |
| Video Resolution (Max) | Up to ~1024 × 768 pixels (typical for legacy industrial HMIs / operator displays) |
| Power Supply Input | 24 V DC (± tolerance per shelf/base unit specification) |
| Power Consumption | Approx. 15 W under typical load (varies with output resolution and usage) |
| Operating Temperature | 0°C to +55°C (standard industrial module range) |
| Storage Temperature | –20°C to +70°C |
| Relative Humidity | 5% to 95% RH, non‑condensing |
| Mounting / Form Factor | Rack‑mounted / slot module compatible with ABB Advant / MasterView cabinets |
| Net Weight | Approx. 0.395 kg |
| Dimensions (approx.) | ~234 mm × 238.5 mm × 27 mm |
| Compliance / Certification | Meets ABB industrial-grade module standards (CE / UL / EMC compliance) |
| Application Scope | Real-time video generation for operator consoles, process monitoring, HMI systems |
FAQ
A1: It supports composite and RGB video output for flexible display integration.Q2: Can it synchronize with external signals?
A2: Yes, it supports internal, external, or mixed synchronization modes.
Q3: What is the operating temperature range?
A3: It reliably operates between 0°C and 55°C.
Q4: Is it compatible with ABB Advant OCS and 800xA systems?
A4: Yes, it integrates seamlessly with both control platforms.
Q5: How much power does the module consume?
A5: Approximate power consumption is 15 W under normal operating conditions.
