Overview
Furthermore, its robust design and precise mechanical fit guarantee long-term reliability and easy installation. Consequently, this blank filler module becomes a practical choice for technicians who prioritize protection, performance, and durability in ABB automation systems.
Specification
| Parameter | Specification |
|---|---|
| Product Type | Blank Filler Module |
| Manufacturer | ABB (Asea Brown Boveri) |
| Model Number | DSBB110 |
| Ordering Code | 57330001E |
| System Compatibility | ABB Master Control System Series |
| Primary Function | Protects unused rack slots and maintains airflow |
| Mounting Type | Plug-in / rack-mounted |
| Material | Industrial-grade thermoplastic (flame-retardant, anti-static) |
| Color | ABB standard light gray |
| Dimensions (H × W × D) | 100 mm × 25 mm × 200 mm (approx., standard ABB format) |
| Weight | 0.10–0.15 kg |
| Operating Temperature | 0°C to +70°C |
| Storage Temperature | -25°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Vibration Resistance | 10–58 Hz, 0.075 mm amplitude |
| Shock Resistance | 10 g for 11 ms (IEC 60068-2 compliant) |
| Cooling Method | Passive airflow through system ventilation |
| Ingress Protection Rating | IP20 (when installed in closed rack) |
| Compliance Standards | CE, RoHS, and IEC 61010-2 |
| Maintenance Requirement | None (fully passive component) |
| Expected Service Life | 10+ years under normal industrial conditions |
FAQ
Q1: What is the main purpose of the ABB DSBB110 module?
A1: It acts as a blank filler that protects unused slots and ensures proper cooling and alignment within ABB Master racks.
Q2: Does the DSBB110 require electrical connections?
A2: No, it is a non-electrical module designed solely for mechanical protection and thermal management.
Q3: Is it compatible with other ABB systems?
A3: It is primarily intended for ABB Master systems but may fit similar ABB rack-based architectures with standard slot dimensions.
Q4: Can it withstand harsh industrial environments?
A4: Yes, the DSBB110 features vibration resistance, high-temperature tolerance, and industrial-grade construction.
Q5: How often should the DSBB110 be replaced?
A5: As a passive component, it typically lasts for the entire service life of the control cabinet unless physically damaged.
