Overview
Specification
| Parameter | Specification |
|---|---|
| Model / Part Number | DO610 / 3BHT300006R1 |
| Module Type | Digital Output Module (Non‑isolated) |
| Output Channels | 32 discrete outputs |
| Output Signal Voltage | 24 V DC nominal |
| Output Signal Current | 200 mA max per channel |
| Minimum Load | 10 mA per channel |
| Maximum Load Resistance | 120 Ω |
| Output ON Voltage | 20–26 V DC |
| Output OFF Voltage | ≤ 5 V DC |
| Switching Speed / Response Time | < 1 ms typical |
| Protection | Individual channel overload and short‑circuit protection |
| Isolation | Non‑isolated outputs |
| Input Logic Compatibility | TTL/24 V DC control signals |
| Power Supply | 5 V DC logic voltage (from system backplane) |
| Power Consumption | Approx. 2 W nominal |
| Mounting | DIN‑rail or panel mountable |
| Physical Dimensions | 252 mm (depth) × 273 mm (height) × 40 mm (width) |
| Weight | Approx. 1.195 kg |
| Operating Temperature Range | –25 °C to +70 °C |
| Storage Temperature Range | –40 °C to +85 °C |
| Humidity | 5–95 % non-condensing |
| Vibration Resistance | 5–9 Hz: ±3.5 mm; 9–150 Hz: 0.5 g |
| Shock Resistance | 15 g, 11 ms half-sine pulse |
| Compliance / Standards | IEC 61131-2, CE, UL508 |
| LED Indicators | Status LEDs for each channel ON/OFF state |
| System Compatibility | ABB Advant OCS control systems, compatible I/O racks |
| Environmental Protection | IP20 (installed in control cabinet) |
FAQ
A1: It offers 32 discrete output channels.
Q2: What output signal voltage and current does it support?
A2: It outputs 24 V DC signals with up to 200 mA per channel.
Q3: What is the switching speed for outputs?
A3: Output switching occurs in under 1 ms, supporting fast automation response.
Q4: Is the module protected against overload or short‑circuit?
A4: Yes — each channel includes protection against overload and short‑circuit to ensure safe operation.
Q5: How is the module mounted?
A5: The module can be mounted on a DIN rail or panel for easy integration into control cabinets.
