Overview
Specification
| Parameter | Specification |
|---|---|
| Model / Part Number | 87TS01‑1551 (GJR2368900R1551) |
| Module Type | Coupling Module / CDS Slave Coupler |
| Function | Signal coupling and isolation for Procontrol P14 station bus / remote data bus |
| Supply Voltage | 24 V DC (station supply) |
| Isolation Method | Optical or transformer coupling (variant‑dependent) |
| Operating Temperature Range | –20 °C to +60 °C |
| Storage Temperature Range | –40 °C to +85 °C |
| Relative Humidity | 5% to 95% RH, non‑condensing |
| Dimensions (approx.) | 290 mm × 130 mm × 35 mm |
| Weight | ~0.5 kg |
| Module Interface | Rack‑mount / sub‑rack slot; standard PROCONTROL bus slot interface |
| Compatibility | PROCONTROL P14, Advant MOD 300, Advant OCS systems (CDS network architecture) |
| Environmental Protection | Designed for industrial control cabinet environments; EMI and ground‑potential protection supported |
FAQ
A: It is compatible with PROCONTROL P14, Advant MOD 300, and Advant OCS distributed control systems.
Q: What does this coupling module do?
A: It connects station bus to remote bus or CDS networks, isolating signals and protecting against surges, ground loops, and EMI.
Q: What is the supply voltage for this module?
A: The module uses a 24 V DC station supply.
Q: Can this module operate under industrial environmental conditions?
A: Yes — it supports –20 °C to +60 °C operating temperature and 5–95% non‑condensing humidity.
Q: Is installation or replacement difficult?
A: No — module mounts into a standard rack slot for easy plug‑in installation or replacement.
Q: How does it protect against electrical disturbances?
A: It uses optical or transformer isolation depending on model variant, shielding the control system from ground‑potential mismatches, surges, and EMI.
