Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | CS513 / 3BSE000435R1 |
| Module Type | MasterBus 300E Communication Module |
| Protocol | MasterBus 300E |
| Network Interface | Two-wire MasterBus line |
| Data Transfer | Cyclic I/O, acyclic configuration, diagnostics |
| Operating Voltage | 24 V DC (typical) |
| Power Consumption | ~1.5 W (typical, depending on load) |
| Operating Temperature | –25 °C to +70 °C |
| Storage Temperature | –40 °C to +85 °C |
| Mounting | Standard DCS rack or subrack |
| Indicators | LEDs for network, module fault, and power status |
| Dimensions | Approx. 160 mm × 100 mm × 40 mm |
| Certification | CE / UL (as part of ABB Advant system) |
| Diagnostics | On-board fault monitoring, network error detection, event logging |
FAQ
It acts as the MasterBus 300E communication interface for ABB Advant OCS controllers and I/O.Q2: How is network status monitored?
LED indicators on the module provide real-time feedback on network health and module faults.Q3: Can it handle diagnostics besides cyclic data?
Yes, it supports acyclic messaging for diagnostics, configuration, and system updates.
Q4: What operating temperature range does it support?
It reliably operates from –25 °C up to +70 °C in typical industrial environments.
Q5: Is firmware upgrade supported without removing the module?
Yes, the CS513 supports in-service firmware updates to enhance or fix communication features.
