Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | SF810‑FOC‑IR‑TL |
| Product Type | Flame Detection Probe / Flame Scanner |
| Sensor Technology | Infrared (IR) photodiode, fiber‑optic cable version |
| Spectral Response Peak | 920 nm (IR) |
| Power Supply | Provided by Flame Analysis Unit (FAU810) |
| Power Consumption | Max ~300 mW (single sensor), up to ~600 mW (dual‑sensor option) |
| Lens Cleaning Air Supply (FOC version) | Air flow ≈ 400 l/min (14 SCFM), min. pressure 300 mm H₂O above wind‑box pressure |
| Fiber‑optic Cable Operating Temperature | Up to 482 °C for IR/VL fiber cables; 350 °C for UV/UVIR fiber types |
| Mounting / Housing Thread | 1″ NPT male mounting thread |
| Protection Class | IP66 / IP67 |
| Compatible Control Unit | Flame Analysis Unit FAU810 (or compatible controller from SF810 series) |
| Supported Fuel Types | Natural gas, light/heavy oil, pulverized coal, mixed fuels |
| Typical Ambient / Environment Use | Industrial boilers, turbines, process heaters, furnaces, power generation plants |
FAQ
A: It uses a fiber‑optic IR sensor that withstands high temperature zones and difficult installation points, offering reliable detection even in harsh conditions.Q: Which fuels can this detector handle?
A: The SF810 series supports multiple fuels — including natural gas, oil, coal, or mixed fuels — making it ideal for versatile industrial combustion systems.Q: Does the scanner require special maintenance for optics?
A: Yes — the fiber‑optic version supports a lens‑cleaning air purge to keep the optical path clear and maintain reliable detection over time.
Q: Is it compatible with ABB control systems?
A: Yes — SF810‑FOC‑IR‑TL works with ABB’s Flame Analysis Unit (FAU810) or other compatible controllers from the SF810 series.
Q: Can this detector handle high‑temperature environments?
A: Yes — with fiber‑optic cable version, the sensor tip tolerates continuous high temperatures (up to about 482 °C for IR/VL cables), ideal for industrial boiler and turbine zones.
