Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | CPM810 |
| Module Type | Common Processor Module (CPU) |
| Supported Platforms | ABB 800xA / 800 Series / Advant OCS / TP800 turbine control systems |
| Processor Type | 32-bit RISC-based CPU with real-time deterministic execution |
| Memory | 512 MB RAM, 2 GB Flash storage for OS, control programs, and event logging |
| Power Supply | 24 V DC ±10%, typical consumption 15 W, max 20 W |
| Operating Temperature | –20 °C to +60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Relative Humidity | 5%–95% non-condensing |
| Mounting / Form Factor | DIN-rail or cabinet rack mount; module fits standard ABB 800 series slots |
| Dimensions (W×H×D) | 106 mm × 160 mm × 44 mm |
| Weight | 0.65 kg |
| Communication Interfaces | Ethernet 10/100/1000 Mbps, Modbus RTU, PROFIBUS DP (slave), RS-232/RS-485 serial ports |
| Redundancy / Reliability | Supports hot-standby CPU configuration, automatic failover, watchdog timers, and fault tolerance |
| Expandability | Can connect multiple analog/digital I/O modules, function modules, and expansion boards |
| Input/Output Capacity | Supports up to 64 digital inputs, 64 digital outputs, 32 analog inputs, and 32 analog outputs per system (depending on configuration) |
| Diagnostics & Logging | Event logging, fault recording, runtime statistics, I/O health monitoring, network diagnostics |
| Firmware & Software | Compatible with ABB Control Builder and 800xA Engineering tools, supports firmware updates without system downtime |
| Environmental Protection | Conforms to industrial standards: vibration, shock, EMC, and temperature for control cabinets |
| Safety Compliance | Designed to meet IEC 61131-2 and relevant industrial automation safety standards |
| Typical Applications | Centralized turbine control, process automation, SCADA/DCS integration, legacy system retrofits |
FAQ
A: CPM810 works with ABB 800xA, Advant OCS, and 800‑series turbine control platforms including TP800.
Q: Which communication protocols does CPM810 support?
A: It supports Ethernet, Modbus RTU, PROFIBUS DP (slave interfaces), RS‑232/RS‑485 serial connections.
Q: Can CPM810 be expanded with additional I/O modules?
A: Yes — its modular architecture allows additional analog or digital I/O modules and external function modules to connect easily.
Q: Is CPM810 suitable for retrofit installations?
A: Yes — the compact and modular design makes CPM810 suitable for retrofitting legacy systems, with minimal cabinet space requirements.
Q: Does CPM810 support redundancy for critical control applications?
A: Yes — the module supports hot‑standby or failover configurations to ensure continued operations in case of processor failure.
Q: What environmental conditions can CPM810 operate under?
A: The module operates reliably in temperatures from –20 °C to +60 °C, suitable for standard industrial control cabinets.
