Overview
Specification
| Parameter | Specification |
|---|---|
| Model / Part Number | SA610 / 3BHT300019R1 |
| Module Type | Power Supply Module |
| Input Voltage | 100–240 VAC, 50/60 Hz |
| Output Voltage | 24 V DC nominal |
| Output Current | Maximum 5 A per module |
| Ripple & Noise | ≤50 mV peak-to-peak |
| Efficiency | ≥85% typical |
| Redundancy Support | Yes, supports N+1 configuration |
| Power Good Signal | Standard signaling to Advant OCS system |
| Operating Temperature Range | 0 °C to +60 °C |
| Storage Temperature Range | –25 °C to +70 °C |
| Relative Humidity | 5% to 95%, non-condensing |
| Indicators | LED for power status and fault detection |
| Mounting | DIN-rail or panel mount compatible |
| Dimensions (D×H×W) | 230 mm × 200 mm × 40 mm |
| Weight | ~1.1 kg |
| Protection | Overvoltage, overload, and short-circuit protection |
| Compliance / Certification | CE, UL recognized, compatible with ABB Advant OCS systems |
FAQ
A1: The module provides a nominal 24 V DC output suitable for Advant OCS I/O modules.
Q2: Can the SA610 support redundant operation?
A2: Yes, it supports N+1 redundancy, ensuring continuous power during maintenance or failure.
Q3: What is the maximum output current?
A3: The module delivers up to 5 A per unit to connected I/O modules.
Q4: What protections are included in the power supply?
A4: Overvoltage, overload, and short-circuit protections safeguard both the module and connected devices.
