Overview
Specification
| Parameter | Specification |
|---|---|
| Model / Part Number | RF620 / 3BHT100011R1 |
| Module Type | Extension Base Back Panel |
| Number of Slots | 10 slots for I/O modules |
| Compatible Modules | ABB Advant OCS Digital and Analog I/O modules |
| Slot Pitch | Standard Advant OCS spacing (approx. 20 mm per slot) |
| Material | Industrial-grade steel with corrosion-resistant powder coating |
| Mounting Type | Rack-mounted, vertical or horizontal installation |
| Mounting Hardware | Included brackets and screws for secure installation |
| Dimensions (D×H×W) | 400 mm × 150 mm × 50 mm |
| Weight | ~2.3 kg |
| Max Load per Slot | Up to 1.5 kg per module |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | –25 °C to +70 °C |
| Relative Humidity | 5% to 95%, non-condensing |
| Electrical Isolation | Each slot isolated according to Advant OCS module standards |
| Safety / Compliance | CE certified, RoHS compliant, meets ABB Advant OCS system requirements |
| Cooling | Passive air circulation within standard control racks |
| Shock / Vibration Resistance | Designed to meet industrial control cabinet standards |
| Maintenance | Easy module insertion/removal without special tools |
| Expansion Capability | Supports seamless integration of additional I/O modules for system scaling |
FAQ
A1: The extension base back panel supports up to 10 Advant OCS I/O modules.
Q2: What is the operating temperature range?
A2: The module operates reliably between 0 °C and +60 °C in industrial environments.
Q3: Can it be mounted in standard control racks?
A3: Yes, the back panel is designed for rack-mounted installation with secure module support.
Q4: Is it compatible with all Advant OCS I/O modules?
A4: The RF620 is compatible with standard ABB Advant OCS I/O modules for seamless integration.
