Overview
Specification
| Parameter | Specification |
|---|---|
| Model / Part Number | DO630 / 3BHT300007R1 |
| Module Type | Digital Output Module (High-Voltage, 16 Channels) |
| Number of Output Channels | 16 discrete outputs |
| Output Type | Relay / Solid-state compatible switching |
| Output Load Voltage | 250 VAC |
| Output Current per Channel | Maximum 2 A |
| Minimum Load Current | 10 mA |
| Switching Type | AC resistive and inductive loads |
| Channel Isolation | Galvanic isolation between channels and from module backplane |
| Response Time | ≤10 ms per channel (typical) |
| Control Logic | Positive logic (ON = signal applied) |
| Input Voltage Supply | 24 V DC (module power supply) |
| Power Consumption | Approx. 3 W (standby), 5 W (all outputs active) |
| LED Indicators | Status LEDs per channel for operational monitoring |
| Module Dimensions (D×H×W) | 252 mm × 273 mm × 40 mm |
| Net Weight | ~1.32 kg |
| Mounting Type | DIN-rail or panel mount compatible |
| Connectors | Screw terminals for field wiring |
| Operating Temperature Range | –25 °C to +70 °C |
| Storage Temperature Range | –40 °C to +85 °C |
| Relative Humidity | 5% to 95% non-condensing |
| Shock & Vibration | Compliant with IEC 61131-2 standards |
| Certifications / Compliance | ABB S600 I/O system compatible, CE, UL recognized |
| Environmental Protection | IP20 (module body), suitable for indoor industrial installation |
FAQ
A1: Each channel can switch up to 250 VAC, making the module suitable for standard AC loads in industrial systems.
Q2: How many output channels does the module provide?
A2: The DO630 provides 16 independent digital output channels.
Q3: Is the module’s output isolated for safety and noise immunity?
A3: Yes — outputs are galvanically isolated, which helps prevent interference and enhances safety in complex installations.
Q4: What is the maximum current per channel?
A4: Each channel supports up to 2 A output, suitable for typical industrial actuators, relays, or motor starters.
