Overview
Specification
| Parameter | Specification |
|---|---|
| Model / Part Number | KSD211B101 / 3BHE022455R1101 |
| Module Type | Input Coupling Unit (ICU) |
| Input Channels | 16 digital input channels |
| Supported Signal Type | Discrete / Binary signals |
| Supply Voltage | 24 V DC ±20% |
| Response Time | ≤ 5 ms typical |
| Signal Isolation | Channel‑to‑channel and system isolation for noise immunity |
| Power Supply Requirements | 24 V DC supply (per system backplane) |
| Operating Temperature Range | 0 °C to +60 °C |
| Storage Temperature Range | –20 °C to +70 °C |
| Relative Humidity (Operating) | 5–95% non‑condensing |
| Mounting Style | Standard DIN‑rail or rack mounting compatible |
| Diagnostics / Indicators | Status LEDs for each input channel to show signal status |
| Module Dimensions (Approx.) | 120 mm × 165 mm × 50 mm (depth × height × width) |
| Weight | ~2 kg |
| Build Quality / Durability | Industrial‑grade design for stable operation in harsh conditions |
| Use Case Scope | Signal conditioning / input coupling for generator or motor excitation control, general DCS/PLC input conditioning |
FAQ
A1: It provides electrical isolation and signal conditioning for input channels, ensuring accurate and reliable signal transmission.
Q2: Which systems is this ICU compatible with?
A2: The KSD211B101 integrates seamlessly with ABB Advant OCS control platforms and I/O modules.
Q3: Can this module prevent signal interference?
A3: Yes, it effectively prevents ground loops and reduces electrical noise in industrial environments.
Q4: What installation methods are supported?
A4: The module supports DIN rail or panel mounting for flexible control cabinet integration.
Q5: Is this module suitable for harsh industrial environments?
A5: Absolutely. It operates reliably from 0–60 °C and 5–95% non-condensing humidity, with robust construction.
Q6: How does it support system maintenance?
A6: The ICU allows safe expansion or maintenance of Advant OCS systems without interrupting ongoing operations.
