Overview
Configured for analog signal termination and field wiring distribution in the GE Mark VI control platform, the General Electric IS200TBAIH1CCC (IS200TBAIH1C Analog Input Terminal Board) provides direct electrical interfacing between field instrumentation and control processors. The board accepts voltage and current process signals, routes them through dedicated terminal connections, and supports analog acquisition circuits operating from a 24 VDC supply architecture within the Mark VI system.
Suffix Breakdown & Model Matrix
The available source information identifies IS200TBAIH1CCC as a specific hardware revision of the IS200TBAIH1C Analog Input Terminal Board. No official suffix decoding details are provided in the supplied documentation; therefore, no further suffix interpretation is included.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | IS200TBAIH1CCC |
| Base Model | IS200TBAIH1C |
| Brand | General Electric |
| Product Type | Analog Input Terminal Board |
| System Platform | GE Mark VI |
| Origin | USA |
| Weight | 1.5 kg |
| Dimensions | 43.3 x 28 x 3.5 cm |
| Voltage Input | +/-10 V, 0-10 V, 0-5 V |
| Current Input | 4-20 mA |
| Nominal Supply Voltage | 24 VDC |
| Power Consumption | 250 mA |
| Operating Temp | -40 deg C to +70 deg C |
| Storage Temp | -40 deg C to +85 deg C |
| Humidity | 5 % to 95 % non-condensing |
| Tariff Code | 8537101190 |
| Shipment Location | Xiamen, China |
Firmware Flash Compatibility and I/O Integration
The IS200TBAIH1CCC functions as a passive field termination assembly within the Mark VI hardware architecture. It provides termination points for analog voltage and current circuits while maintaining signal routing between field devices and associated control electronics.
Because terminal boards operate alongside processor and I/O assemblies, compatibility should be verified against the installed Mark VI hardware revision. During maintenance activities, technicians should confirm connector alignment, terminal assignments, and board revision matching before system energization. Furthermore, proper field wiring practices help maintain signal integrity when multiple analog channels operate within the same cabinet.
Frequently Asked Questions
Q: Does the IS200TBAIH1CCC process analog signals directly?
A: No. The board primarily provides field termination and signal routing functions. Analog signal conversion and processing occur in the associated I/O electronics within the Mark VI system.
Q: Which field signal types can be connected to this terminal board?
A: The specified supported inputs include +/-10 V, 0-10 V, 0-5 V voltage signals and 4-20 mA current loops.
Q: What should be checked before replacing the board during maintenance?
A: Verify the hardware revision, terminal wiring identification, connector orientation, grounding continuity, and compatibility with the installed Mark VI I/O assembly before applying power.
Field Installation Guidelines
- De-energize the associated control cabinet before installing or removing field wiring.
- Route analog signal cables separately from high-current power conductors to reduce induced electrical noise.
- Terminate cable shields according to plant grounding standards and maintain a single-point shield grounding strategy where applicable.
- Confirm terminal identification against the approved wiring drawings before field commissioning.
- Inspect all terminal screws for proper torque and verify conductor retention after installation.
- After wiring completion, validate input signal ranges and polarity before placing the channel into service.
