Overview
Specification
| Specification | Details |
|---|---|
| Model / Type | 5466-253 |
| Manufacturer | Woodward |
| Module Type | MicroNet Digital Control HD Combo Module |
| Input Power | 24 Vdc nominal, 0.6 A typical |
| Digital Communication | MicroNet serial interface, high-speed network |
| Functions Integrated | Speed control, load control, monitoring, alarms |
| Number of Modules | Single module, HD combo |
| Mounting | Panel-mounted |
| Dimensions | 190 mm x 130 mm x 80 mm (L×W×H) |
| Weight | 1.1 kg |
| Operating Temperature | -40°C to 70°C (-40°F to 158°F) |
| Humidity | 95% non-condensing |
| Approvals / Compliance | CE, RoHS compliant |
FAQ
A1: The 5466-253 integrates speed control, load management, monitoring, and alarm functionality.Q2: What power supply does this module require?
A2: It operates on a nominal 24 Vdc, drawing approximately 0.6 A.Q3: What communication protocol is supported?
A3: The module uses the MicroNet serial interface for high-speed data exchange.
Q4: Can the module handle harsh industrial conditions?
A4: Yes, it operates reliably in temperatures from -40°C to 70°C with 95% non-condensing humidity.
Q5: How large is the module and its weight?
A5: Dimensions are 190 × 130 × 80 mm, and it weighs approximately 1.1 kg.
