Overview
With advanced input filtering and isolation, the 140DDI35300 ensures signal integrity while protecting against electrical disturbances. Its compact design and standard module format allow seamless installation into existing racks, reducing downtime during upgrades.
Specification
| Feature | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Range of Product | Modicon Quantum |
| Model | 140DDI35300 |
| Module Type | Discrete Input Module |
| Discrete Inputs | 32 |
| Input Voltage | 24 V DC |
| Input Current | ≤ 7 mA |
| Input Type | Sinking |
| Input Filtering | 4 ms typical, 7 ms maximum |
| Response Time | 0.75–4.9 ms (Off-On), 7.3–12.3 ms (On-Off) |
| Isolation Between Channels | 1780 Vrms for 1 minute |
| Isolation Between Channels and Bus | 1780 Vrms for 1 minute |
| Bus Current Requirement | 180 mA |
| Power Dissipation | ≤ 5.5 W |
| Status LEDs | 32 green (channel status), 1 green (bus active), 1 red (fault) |
| Module Format | Standard |
| Operating Temperature | 0–60°C |
| Storage Temperature | -40–85°C |
| Relative Humidity | 95 % without condensation |
| Weight | 0.35 kg |
| Certifications | CUL, FM Class 1 Division 2 |
| Standards | UL 508, CSA C22.2 No 142 |
| EMC Resistance | 10 V/m, 80–2000 MHz, IEC 801-3 |
| Operating Altitude | ≤ 5000 m |
FAQ
Q1: Is the 140DDI35300 new and genuine?
A: Yes, it is 100% brand new and factory-sealed.
Q2: What is the typical shipping time?
A: Orders ship within 3 days to 2 weeks depending on quantity and logistics options like DHL.
Q3: What if the module has a quality issue?
A: We support returns within 30 days for any quality-related issues.
Q4: How many inputs can I connect per module?
A: This module supports 32 discrete DC inputs for various industrial sensors.
Q5: What is the operating temperature range?
A: The 140DDI35300 functions between 0–60°C and can be stored at -40–85°C.
