Overview
The General Electric IS200AEPCH1ABC, also cataloged as the IS200BPPBH2BJD printed circuit board, provides direct physical and electrical execution for BPPC-based I/O pack control functions within the GE Mark VI control system platform.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | IS200AEPCH1ABC |
| Brand | General Electric |
| Product Type | Mark VI Printed Circuit Board |
| Spare Model | IS200AEPCH1A |
| Origin | USA |
| Weight | 1.9 kg |
| Dimensions | 43.1 x 35.2 x 5 cm |
| Operating Temp | 0 deg C to +60 deg C |
| Storage Temp | -40 deg C to +85 deg C |
| Humidity | 5% to 95% non-condensing |
| Power Input | 28 V DC |
| Output Rating | +5 VDC / 6 A |
| Power Consumption | 150 W max |
| Tariff Code | 8537101190 |
GE Mark VI Backplane Communication and I/O Integration
The IS200AEPCH1ABC IS200BPPBH2BJD operates as a Mark VI control system circuit board designed for BPPC-based I/O pack interfaces. The board manages electrical connections between control processing assemblies and associated I/O hardware.
Furthermore, the module follows GE industrial control architecture requirements for backplane bus communication velocity and firmware flash compatibility. The hardware design supports deterministic data transfer between control modules while maintaining defined signal paths inside the Mark VI rack environment.
The board configuration supports I/O density scaling within the Mark VI platform by providing a standardized connection interface for system-level control expansion.
Frequently Asked Questions
Q: What is the primary function of the IS200AEPCH1ABC IS200BPPBH2BJD board?
A: The board functions as a Mark VI printed circuit board assembly used for BPPC-based I/O pack integration and control system interfacing.
Q: What power input and output ratings apply to this circuit board?
A: The board accepts a 28 V DC power input and provides +5 VDC output capability at 6 A, with a maximum total power rating of 150 W.
Q: Can the board operate outside the specified environmental range?
A: The specified operating range is 0 deg C to +60 deg C with 5% to 95% non-condensing humidity. Installation should maintain environmental conditions within these limits.
Field Installation Guidelines
- Verify the board part number and revision marking before installation into the Mark VI rack assembly.
- Confirm that the rack backplane connector is clean and free from mechanical damage before insertion.
- Disconnect system power before removing or installing the circuit board.
- Maintain proper grounding practices for the control cabinet to reduce electrical noise and signal interference.
- Route power and signal wiring separately where possible to minimize coupling effects.
- Inspect connector seating after installation to ensure full mechanical engagement.
- Follow GE Mark VI system documentation for firmware compatibility checks and module replacement procedures.
